LOGIPAC 51e – HIGH SPEED PACKAGING MACHINE

LOGIPAC 51e – HIGH SPEED PACKAGING MACHINE

SERVO BASED, FORM-FILL AND SEAL MACHINE FOR BISCUIT STACKED ON EDGE

HIGHLIGHT
» Fastest biscuit size change in its class
» No size change parts needed
» ‘No biscuit no pack’ interlock
» Discharge with 2 in 1 option: Dual belt/chain system
» 7 servo\PLC system with touch screen HMI

Category: .

STANDARD FEATURES
» EASY, QUICK AND FOOL PROOF CHANGE OVER
Logipac 51E uses multiple axes servo control for timing the machine. All the machine timings after the optimization can be stored as a receipe for that size and can be quickly recalled whenever machine has to be set for that size. A few position settings that need to be done manually are simple and can be marked on graduated scale.

» NO – PACKET – NO WRAP INTERLOCK
In a slug packing machine many times a slug is taken off the infeed conveyor for quality reason. If the wrapper keeps flowing continuously it results into empty pack which is counted as wastage. Logipac 51E has a feature to stop wrapper for empty infeed cycle that would have got wasted.

» OPTIONS FOR STACK CONTROL
In a slug wrapping machine, the slug after it enters the wrapper needs to be held from sides. This can be done either by means of soft pressure belts that gently press the stack so that the biscuits donot tip over, or by means of chain mounted tuckers that press the wrapper in the empty space between the stacks. Both the methods have their relative advantages. Logipac 51E allows you to select any of these two options for any size change.

» SPLICING OF WRAPPER
Logipac 51E has the feature of automatic splicing of wrapper as its roll finishes, thereby reducing the downtime for roll change.

HIGHLIGHT
» Fastest biscuit size change in its class
» No size change parts needed
» ‘No biscuit no pack’ interlock
» Discharge with 2 in 1 option: Dual belt/chain system
» 7 servo\PLC system with touch screen HMI

PRODUCT SPECIFICATION

PRODUCT SIZE (all dimensions in mm)
LenghtWidthHeight
L MAX 200W MAX 65H MAX 62
L MIN 65W MIN 35H MIN 24
other dimensions may be considered on request combination of max. sizes may be out of the range of specifications
WRAPPING MATERIAL WRAPPER : BOPP, BOPP/PE AND OTHER SEALABLE FILMS AND LAMINATES
OUTSIDE DIA 400mm   CORE DIA 70mmSPEED UPTO 160 PPM INFINITELY VARIABLMACHINE WEIGHT : 2400 Kgs.

ELECTRICALS:

» SUPPLY VOLTAGE : 3 PHASE 220V, 50HZ
» POWER: 5KW
» CONTROL VOLTAGE : 24V DC
