LOGIPAC-22S – HIGH SPEED PACKAGING MACHINE

LOGIPAC-22S – HIGH SPEED PACKAGING MACHINE

SERVO BASED HIGH SPEED HORIZONTAL FLOW WRAP MACHINE FOR SOAP

Highlights
» High speed
» High productivity
» Fool proof size changeability
» No parts needed to change soap size Gentle handling of soaps
» Servo controlled operation
» 3 axes servo controls
Options
» Inkjet Printer
» Gussetting Unit
MACHINE SPEED UPTO 250 PPM INFINITELY VARIABLE

STANDARD FEATURES
» Soap is automatically positioned by servo based ‘Smart Conveyor’
» Infeed conveyor with carrier lugs- soap is carried to avoid any scratch / dent marks .3 axes servo controls
» Double set of sealing jaws for high speed operation
» All parts in contact with soap made of stainless steel or nylon. Two wrapper spool holders
» Positive drive to wrapper unwind
» AC frequency control drive to infinitely vary speed from 50 to 250 ppm
» Additional static heater for long seal
» Fine adjustments of knives and jaw pressure by means of adjusting screws
» 50V supply to heaters for operator’s safety. PLC control of eye-mark registration
» Touch screen HMI display of speed, shift output and settings
» Trolley wheels
» Additional static heater for long seal
» All variable settings marked on scales for fool proof size change
» Optional gusseting unit
» Imported Instrumentation

Highlights
» High speed
» High productivity
» Fool proof size changeability
» No parts needed to change soap size Gentle handling of soaps
» Servo controlled operation
» 3 axes servo controls
Options
» Inkjet Printer
» Gussetting Unit
MACHINE SPEED UPTO 250 PPM INFINITELY VARIABLE

PRODUCT SPECIFICATION

PRODUCT SIZE (all dimensions in mm)
LenghtWidthHeight
L MAX 200W MAX 70H MAX 60
L MIN 40W MIN 25H MIN 5
other dimensions may be considered on request combination of max. sizes may be out of the range of specifications
WRAPPER : PAPER / POLY / HOTMELT LAMINATION MAX DIA 400mm CORE DIA 70mm
MATERIAL : BOPP, BOPP/PE AND OTHER SEALABLE FILMS AND LIMINATES STIFFENER: CARD PAPER / POLY LAMINATESTIFFENER: CARD PAPER / POLY LAMINATESPEED UPTO 250 PPM INFINITELY VARIABLE

MACHINE WEIGHT 2400 Kgs. APPROX.

ELECTRICALS:

» SUPPLY VOLTAGE: 3 PHASE 220V, 50 Hz
» CONTROL VOLTAGE 24V DC
» MOTOR 2HP 3 PHASE
» HEATERS 3.3 KW 55V
