PRINCPLE OF OPERATION:
2 rows of soaps are placed edge ways on flat belt conveyor, either by link up conveyor (not a part of the of the machine) or manually. Autofeeder transfers these soaps to the infeed lug conveyor of the machine. Infeed conveyor then transfers multi soap into wrapping film that has been formed into a tube by means of forming folder. Bottom seal is made by three sets of rollers. Cross sealing and cutting knife separate the packed soaps. Heat sealable material like BOPP or laminates is used.
STANDARD FEATURES
All surfaces over which soaps are transported are made of stainless steel Flat belt conveyor infeed with Transfer Unit Long seal is formed by means of three pairs of rollers, axes of which can be tilted to get best results Torque slip clutch to prevent damage in case of accidental jams Low voltage heaters for safety Individual temperature controls for heaters rint registration unit for printed wrapper Heavy distortion-free cast structure
Highlights
» High speed
» High productivity
» Fool proof size changeability
» No parts needed to change soap size Gentle handling of soaps
» Servo controlled operation
» 3 axes servo controls
Optional Features:
» Date Printing unit » Variable speed drive (AC frequency control) » Castors for mobility of machine MACHINE SPEED UPTO 120 PPM INFINITELY VARIABLE
