WRAPPER 4000T – HIGH SPEED PACKAGING MACHINE

WRAPPER 4000T – HIGH SPEED PACKAGING MACHINE

HOTEL TOILET SOAP WRAPPING MACHINE

Highlights
» Low and easy maintenance
» Link ability
» High Productivity
» Easy soap size change

Options: » Inkjet coder
» Flexible infeed conveyor to suit plant layout
» Collator on discharge for easy pickup of soap e Conversion parts for size change
» Conversion parts for size change

MACHINE SPEED UPTO 160 PPM INFINITELY VARIABLE

STANDARD FEATURES
» Outer wrapper and inner stiffener
» High speed operation of upto 160 tablets per minute
» The new design Autofeed Conveyor provides attention free linking with the cutting machine / stamping machine to match the speed of production
» Excellent quality of soap handling, even for soft soap
» Timing Belts allow maintenance free operation for longperiods
» Automatic centralised lubricationl Double spool holder to save reel change over time, integrated with “wrapper-break-machine-stop” interlock
» Simple to maintain “no-soap-no-wrap” interlock
» Long top and side heaters with Cooling Plates for reliable sealing at high speeds
» Digital temperature controllers for all heaters (separate front and rear side heaters)
» Worm drive for accurate print correction
» Easy height adjustment of cutoff unit and discharge conveyor
» Completely guarded drives
» All parts in contact with soap are either stainless steel or coated with Teflon. Conveyor belt is of food grade quality

Highlights
» Low and easy maintenance
» Link ability
» High Productivity
» Easy soap size change

Options: » Inkjet coder
» Flexible infeed conveyor to suit plant layout
» Collator on discharge for easy pickup of soap e Conversion parts for size change
» Conversion parts for size change

MACHINE SPEED UPTO 160 PPM INFINITELY VARIABLE

PRODUCT SPECIFICATION

PRODUCT SIZE (all dimensions in mm)
Lenght Width Height
L MAX 35 W MAX 65 H MAX 45
L MIN 65 W MIN 35 H MIN 13
other dimensions may be considered on request combination of max. sizes may be out of the range of specifications
WRAPPER : PAPER / POLY / HOTMELT LAMINATION MAX DIA 400mm CORE DIA 70mm
STIFFENER: CARD PAPER / POLY LAMINATESTIFFENER: CARD PAPER / POLY LAMINATESPEED UPTO 240 PPM INFINITELY VARIABLE

MACHINE WEIGHT 1800 Kgs. APPROX.

ELECTRICALS:

» SUPPLY VOLTAGE 3 PHASE 220V, 50 Hz
» CONTROL VOLTAGE 24V DC
» MOTOR 2HP 3 PHASE
» HEATERS 3.3 KW 55V
» Three AXES SERVO CONTROL BY
» ROCKWELL AUTOMATION

OPTIONS:

» Flexible infeed conveyor to suit plant layout
» Automatic White Oil application for outside polycoated Wrapper
» Conversion parts for size change
» Linkup with automatic banding machine ABM 1100

FLOOR-LAYOUT
HT. OF INFEED CONVEYOR
(ABOVE THE GROUND LEVEL) =833 MMHT. OF DISCHARGE CONVEYOR
(ABOVE THE GROUND LEVEL) =743 MMHT. OF THE MACHINE
(ABOVE THE GROUND LEVEL) =2130 MM
